CDK Express Pipeline Tutorial

The AWS CDK Express Pipeline library helps you create simple and fast deployment pipelines using the AWS CDK. This tutorial shows you how to set up and manage deployment pipelines with the cdk-express-pipeline library.

cdk-express-pipeline is available in Python and TypeScript. This guide uses TypeScript.

What is the CDK Express Pipeline?

The library uses the CDK CLI’s ability to determine the correct order of stack deployments based on dependencies. It creates a dependency graph between Waves, Stages and Stacks using the native .addDependency method of the CDK Stack. Running cdk deploy '**' will deploy all stacks in the right order.

This tutorial will show you how to deploy an SNS topic in two regions: us-east-1 and eu-west-1.

Prerequisites

Before starting, make sure you have:

1. Node.js (v22.x or later) and npm installed
2. AWS CDK CLI installed (npm install -g aws-cdk)
3. AWS account and configured credentials profile as ADMIN_PROFILE
4. Basic understanding of AWS CDK
5. CDK Bootstrapped accounts in the us-east-1 and eu-west-1 regions.

   cdk bootstrap aws://ACCOUNT_ID/us-east-1 --profile ADMIN_PROFILE
   cdk bootstrap aws://ACCOUNT_ID/eu-west-1 --profile ADMIN_PROFILE


6. [OPTIONAL] GitHub account with AWS OIDC Connection. Create an IAM role in your AWS Account that lets GitHub assume the role for deployments.
   • Name the role githuboidc-git-hub-deploy-role
   • Add the AdministratorAccess policy
   • Use this trust relationship:

   {
       "Version": "2012-10-17",
       "Statement": [
           {
               "Effect": "Allow",
               "Principal": {
                   "Federated": "arn:aws:iam::ACCOUNT_ID:oidc-provider/token.actions.githubusercontent.com"
               },
               "Action": "sts:AssumeRoleWithWebIdentity",
               "Condition": {
                   "StringEquals": {
                       "token.actions.githubusercontent.com:aud": "sts.amazonaws.com"
                   },
                   "StringLike": {
                       "token.actions.githubusercontent.com:sub": "repo:GITHUB_USERNAME/GITHUB_REPO_NAME:*"
                   }
               }
           }
       ]
   }


Project Setup

1. Create a new CDK TypeScript project:

   mkdir my-pipeline-stack
   cd my-pipeline-stack
   cdk init app --language typescript


2. Install the required dependencies:

   npm install cdk-express-pipeline aws-cdk-lib constructs


3. Update the lib/my-pipeline-stack.ts file to extend ExpressStack and add an SNS Topic:

   import * as cdk from 'aws-cdk-lib';
   import { Construct } from 'constructs';
   import {ExpressStack, ExpressStage} from "cdk-express-pipeline";
   import {StackProps} from "aws-cdk-lib";

   export class MyPipelineStack extends ExpressStack {
     constructor(scope: Construct, id: string, stage: ExpressStage, stackProps?: StackProps) {
       super(scope, id, stage, stackProps);

       new cdk.aws_sns.Topic(this, 'MyTopic');
       // ... more resources
     }
   }


4. Update the bin/my-pipeline.ts file to define the pipeline:

   #!/usr/bin/env node
   import 'source-map-support/register';
   import {MyPipelineStack} from '../lib/my-pipeline-stack';
   import {App} from "aws-cdk-lib";
   import {CdkExpressPipeline} from "cdk-express-pipeline";

   const app = new App();
   const expressPipeline = new CdkExpressPipeline();

   // === Wave 1 ===
   const wave1 = expressPipeline.addWave('Default');

   // --- Wave 1, Stage US ---
   const wave1StageUs = wave1.addStage('MyAppUS');
   new MyPipelineStack(app, 'AppStack', wave1StageUs, {env: { account: "581184285249", region: "us-east-1" }});

   // --- Wave 1, Stage EU ---
   const wave1StageEu = wave1.addStage('MyAppEU');
   new MyPipelineStack(app, 'AppStack', wave1StageEu, {env: { account: "581184285249", region: "eu-west-1" }});

   expressPipeline.synth([
     wave1,
   ]);


5. Check the changes locally:

   cdk diff '**' --profile ADMIN_PROFILE


   The output will show the deployment order and new resources:

   ORDER OF DEPLOYMENT
   🌊 Waves  - Deployed sequentially
   🔲 Stages - Deployed in parallel, all stages within a wave are deployed at the same time
   📄 Stack  - Dependency driven, will be deployed after all its dependent stacks, denoted by ↳ below it, is deployed

   🌊 Default
     🔲 MyAppUS
       📄 AppStack (Default_MyAppUS_AppStack)
     🔲 MyAppEU
       📄 AppStack (Default_MyAppEU_AppStack)

   Stack Default_MyAppUS_AppStack (AppStack)
   Parameters
   [+] Parameter BootstrapVersion BootstrapVersion: {"Type":"AWS::SSM::Parameter::Value<String>","Default":"/cdk-bootstrap/hnb659fds/version","Description":"Version of the CDK Bootstrap resources in this environment, automatically retrieved from SSM Parameter Store. [cdk:skip]"}
   Resources
   [+] AWS::SNS::Topic MyTopic MyTopic86869434

   Stack Default_MyAppEU_AppStack (AppStack)
   Parameters
   [+] Parameter BootstrapVersion BootstrapVersion: {"Type":"AWS::SSM::Parameter::Value<String>","Default":"/cdk-bootstrap/hnb659fds/version","Description":"Version of the CDK Bootstrap resources in this environment, automatically retrieved from SSM Parameter Store. [cdk:skip]"}
   Resources
   [+] AWS::SNS::Topic MyTopic MyTopic86869434


   ✨  Number of stacks with differences: 2


6. Deploy the stack from your machine:

   cdk deploy '**' --concurrency 10 --profile ADMIN_PROFILE


7. Create a GitHub Workflow for our pipeline, that will run on push to the main branch. Create .github/workflows/cdk-deploy.yml:

   name: Deploy
   on:
      push:
         branches:
            - main

   env:
      FORCE_COLOR: 1

   jobs:
      deploy:
         name: CDK Diff and Deploy
         runs-on: ubuntu-latest
         permissions:
            actions: write
            contents: read
            id-token: write
         steps:
            - name: Checkout repo
              uses: actions/checkout@v4

            - name: Set up node
              uses: actions/setup-node@v3
              with:
                 node-version: 20
                 cache: npm

            - name: Install dependencies
              run: npm install ci

            # TODO: Alternatively use an AWS IAM user and set the credentials in GitHub Secrets (less secure than GH OIDC below)
            - name: Configure AWS credentials
              uses: aws-actions/configure-aws-credentials@v4
              with:
                 role-to-assume: # TODO: Your role to assume
                 aws-region: # TODO: your region

            - name: CDK diff
              run: npm run cdk -- diff '**'

            - name: CDK deploy
              run: npm run cdk -- deploy '**' --require-approval never --concurrency 10


Understanding Core Concepts

Waves and Stages

CDK Express Pipeline organizes deployments into Waves and Stages:

1. Waves: Top-level groups that deploy sequentially, one after another
2. Stages: Groups of stacks within a wave that can deploy at the same time

Here’s an example:

Wave1
  ├── Stage1
  │   ├── StackA
  │   └── StackB
  └── Stage2
      └── StackC
Wave2
  └── Stage1
      └── StackD

All stacks in Wave1 deploy at the same time since they’re in stages that can run in parallel. The two stacks in Wave1_Stage1 also deploy together since they don’t depend on each other.

Wave2_Stage1_StackD needs to wait for all Wave1 stacks to finish. This is created with .addDependency between these stacks:

• Wave2_Stage1_StackD depends on Wave1_Stage1_StackA
• Wave2_Stage1_StackD depends on Wave1_Stage1_StackB
• Wave2_Stage1_StackD depends on Wave1_Stage2_StackC

CDK Express Pipeline handles creating these dependencies for you. The addWave and addStage functions, along with stack stage inheritance, build this structure. When you call expressPipeline.synth(waves), it builds the dependency graph and lets CDK handle the rest.

Concurrency

The --concurrency flag in the cdk deploy command lets CDK deploy multiple stacks at once when possible:

cdk deploy '**' --concurrency 10 --profile ADMIN_PROFILE

CDK Express Pipeline uses this feature to speed up deployments by running independent stacks in parallel.

FAQ

How does CDK Express Pipeline differ from CDK Pipelines?

1. CDK Express Pipeline works locally and on any CI/CD system. CDK Pipelines only works with AWS CodePipeline.

2. CDK Express Pipeline uses a single cdk deploy command. CDK Pipelines needs a complex pre-asset generation phase.

3. CDK Express Pipeline uses standard CDK bootstrapping. CDK Pipelines requires extra cross-account and region setup stacks.

4. CDK Express Pipeline runs faster than CDK Pipelines since it doesn’t need to modify the pipeline or use separate CodeBuild projects.

5. CDK Express Pipeline lets you rename stages and move stacks without breaking resources. CDK Pipelines uses the CDK Stage Construct which can force resource replacements when making these changes.

   One example of this is the SecurityGroup description property. It can not change without replacing the SecurityGroup, of which many times you can not because other SecurityGroup rules depend on it. There are a few more resources like this that causes replacement when you want to rename stages or move stacks between stages. CDK Express Pipeline uses pure classes, not inheriting from the CDK Construct class, allowing the rename of stage names and moving stacks between stages without any issues.

Additional resources

For more information, check the official documentation it contains many additional features and examples not covered in this tutorial. A full project example can be found in the demo project.

A YouTube video exploring the library and it’s existence is available here.

Conclusion

CDK Express Pipeline makes AWS infrastructure deployments simple and fast. This tutorial showed you how to create organized deployment pipelines using AWS CDK.

---

---
